BIOLUMINESCENT FANTASY CREATURE
UNREAL ENGINE 5
BLENDER
Through this project I explored Unreal Engine's Substrate Slab BSDFs and how these new shaders work in combination with traditional Parallax Occlusion Maps, World Space Operations, UV Animations and Vertex Animations.
​
Furthermore, I gauged the Shader's performance at different optimization levels to determine it's viability for real-time applications.
​
This creature is based on the following 2D Concept by Dave Melvin:
MATERIAL FEATURES
SUBSTRATE PARALLAXING
For the parallax effect I used parallax occlusion mapping in combination with substrate shaders which allow for using two BSDFs layered by thickness.
​
I created two different Normal Maps: Surface and Internal, then parallax mapped the internal layer by a specified substrate thickness to achieve the internal organ look.
​
The same technique was also used for the emissive layers.
Surface Normals
Internal Normals
Surface Emissions
Internal Emissions
VERTEX ANIMATION
For the breathing Vertex animation I used a hand-painted mask with a sine wave multiplier and additional time period as well as intensity parameters to achieve a frog-like expanding membrane look.
Breathing Material Function
WORLD SPACE IRIDESCENCE
For Iridescence I used World Space operations to lerp a Hue Shift based on Pixel Normals and Camera Vector with the Base Color, this gave me a subtle Oil-Slick Aesthetic which covers the creature's skin.
EMISSION MODES
PULSE
FLOW
For the multiple internal layers, Besides Parallaxing I added two effects, Pulsing and Flowing. For Pulsing I simply animated the intensity of the Emission Map with a Sine wave. For Flowing I rotated a Tileable Texture over time as a Multiplier for the Emissive Intensity which gave me a smooth flowing effect throughout the internal emissions.
​
To parameterize the effects I added a switch to select between the two behaviors or even combine the pulsing with the flowing.
ANIMATED EMISSION LAYERS
The surface layer consists of 3 Kinds of emissive behaviors:
-
Static Tail, Ear and Arms Emissive
-
Breathing Throat Membrane Emissive
-
Micro moving stars-like dots Emissive
​
To achieve this these three effects I used different textures with different operations being applied on them, then these operations were added to combine in a material function.
​
The static emissive is added last as it is.
​
The breathing throat membrane texture is localized to the throat only and is multiplied by the same sine wave as the vertex animation displacement mask.
​
The micro dots are painted evenly and then are multiplied by a tiling rotating noise texture to give them the illusion of random generation across the surface.
​
​
